CS-872

The CEDAR Special CS-872 is a Belt Driven, twin-needle, heavy-duty industrial sewing machine. It is designed for making two parallel rows of stitching at the same time.

Uses:

        * Factories use it for canvas, leather, and heavy fabrics.  It is ideal to be equipped with a Rear Puller or Side Belt Puller for long runs.

The key specifications include:

     * Belt Drive

     * 750W Servo Motor ( Available in 110V or 220V )

     * Max Speed: Up to 3,000 stitches per minute.

     * Stitch Length: Up to 7 mm.

     * Needle Feed: Both the needle and the bottom "feed dog" (the metal teeth under the fabric) move to pull thick fabrics evenly.

     * Presser Foot Lift: Up to 13 mm with a knee lifter.

     * Needle Type: Uses DP × 5 needles.

     * Hook: Uses large vertical rotary hooks for larger bobbins.

     * Needle Gauges: Available gauge set sizes: 1/8" (3.2 mm), 3/16" (4.8 mm), 1/4" (6.4 mm), 3/8" (9.5 mm), up to 1/2" (12.7 mm) and higher depending on the specific application block installed.

  -   Special Automated Machines are Available.  Check with one of our experienced representatives  -

 * Custom Folders, Binders, Hemmers, Guides, Pallets and Clamp Sets for the Sewn Products Industry.

          For more information, call or email.

             •    Phone: (256) 229-6595

             •    Email: CEDAR-Special@CollierEquipment.com
