MH-2645-270

Mauser Spezial MH-2645-270242 33

Double Needle, Walking Foot Machine a/k/a Triple Feed or Compound Feed.

   * Features

          * Electro-Magnetic Thread Trimmer

          * Electro-Magnetic Presser Foot Lift

          * Electro-Magnetic Backtack & Quick Stroke Adjustment

          * Presser Foot Lift: Up to 20mm

          * Maximum Stitch Length: 9mm

          * Thread Size: Up to Nm 10/3 (Tex 300)

          * Drive System: 750W Direct Drive

   * Ergonomic and powerful single needle triple feed flatbed machine with integrated, high-torque direct drive and control panel.

   * Equipped with electro-magnetic thread trimmer, electro-pneumatic presser foot lift, electro-magnetic seam backtacking and quick stroke adjustment.

   * The uniform material feed in conjunction with the quick stroke adjustment ensures a consistent - high seam quality, even when overstitching cross seams.

   * The ergonomic equipment and the sewing parameters of the machine class MH-2645-270242-33 meet the highest demands of all the users.

   * The foot lift of up to 20mm allows effortless insertion of even voluminous material.

   * The narrow sewing head with integrated LED light allows a perfect view of the sewing material at any time.

   * The stroke height of the sewing feet is easily adjustable via a rotary dial.

   * The standard quick stroke adjustment of the presser foot allows quick switching from standard stroke to high stroke and back by means of a knee lever.

   * Needle threads up to Nm10/3 (Tex300) can be processed, which also allows decorative seams with thick threads and a stitch length of up to 9mm.

   * With a variety of different sewing components, the machine is a versatile tool in your day to day business.  With the optional thread nipper you will have a clean seam start with both threads pulled to the bottom side of the sewn material.

   * The MH2645-270242-33 is a workhorse for a wide range of sewing operations, especially in the upholstery, automotive and leather goods industry.

   * Integrated Direct Drive and Control Panel

        - The integrated control panel allows easy access to the main sewing parameters and cares for a clean setup of the machine.

   * Quick Stroke Adjustment

        - The dial allows you to set your sewing foot stroke for your common sewing operation and benefit from maximum sewing speed.  To climb over cross seams just activate the maximum foot stroke by pushing the knee switch.  Machine speed will be reduced automatically.  Pushing the knee switch again will get you back to your standard foot stroke.

        * Custom Folders, Binders, Guides and Clamps Sets for the Sewn Products Industry.
