MH2645-75

The Mauser Spezial MH2645-270242-36-75, Double-needle flatbed heavy-duty machine with XXL extra large vertical rotary hook, dual stitch length, dual presser foot stroke function, and extra-wide workspace (750 mm).

               -  Order MH2642 for Needle Feed Version  -

     * Features dual stitch length settings and dual, adjustable presser foot stroke.

     * Powerful triple feed system: bottom feed, needle feed, and alternating presser foot feed.

     * Touch-type control panel, integrated electronic control (direct drive motor), with multifunctional head shortcut keys such as reinforcement stitching and secondary thread tension adjustment.

     * Automatic thread trimming, automatic back stitching, pneumatic presser foot lifting, and HP mechanism for quick adjustment of alternating presser foot stroke, with maximum differential feed of 9 mm, ensuring safe stitching over varying fabric thicknesses.

     * XXL extra-large vertical rotary hook enhances productivity (bobbin diameter Ø32 mm; 70% higher bobbin capacity compared to standard Ø26 mm bobbins).

     * Presser foot lift height up to 20 mm, facilitating easy loading and unloading of thick and bulky workpieces.

     * Stitch length adjustment knob (adjustable stitch length), maximum stitch length 9 mm.

     * 750 mm wide x 125 mm high under-arm space.

     * Optional needle gauge: 6 mm, 8 mm, 10 mm, etc.

Contact us for more information.

 * Custom Folders, Binders, Guides and Clamps Sets for the Sewn Products Industry.

          For more information, call or email.
