Catalog Categories
Scroll down for machinery
Machine Brands
Browse our high-performance line of Machine Brands. Built for reliability, durability, and operational efficiency.
Cedar Special
CS-1760N
Double Needle Post Bed Machine
*Belt type
* Needle Gauge : Available in different needle gauges.
* The CS-1760 is a post-bed, 2-needle, unison-feed lockstitch machine designed for heavy-duty applications like car seats, furniture, and leather goods. It features an alternating vertical movement mechanism to prevent irregular stitches and is prized by professionals for handling thick materials up to 16 mm thick.
* Feed Mechanism: Unison feed (drop feed, needle feed, and walking foot) prevents slippage when sewing multiple thick layers.
* Stitch Capacity: Handles large stitch lengths up to 9mm to 12mm, ideal for thick threads and decorative topstitching.
* Clearance: Post-bed height typically ranges between 7 to 8 inches, giving you excellent maneuverability for tight, inside curves and corners.
* Hooks: Equipped with large vertical-axis hooks or extra-large bobbins to accommodate thick industrial threads (like TEX 138) without constant refilling.
Usage and Applications
* Post-bed machines excel where flatbed machines fail: allowing irregular and pre-assembled 3D shapes to rotate freely around the elevated pillar.
* Bags & Footwear: Excellent for gussets, boxing, and adding structural piping.
* Topstitching: Many operators use spring-loaded edge-guide feet to achieve flawless parallel topstitching on curved edges.
* Folders and Guides are available *
Cedar Special
CS-1987NF
Introducing our CS-1987NF, Single Needle, Needle Feed industrial sewing machine.
Machine features include;
* Needle feed
* Fully automatic
* Pattern sewing
* "Bar tack"
* 1/4 and 1/2 stitch buttons
* Easy to use touch screen
* Semi-dry head
* Two stepping motor operation to control stitch length, presser foot lift, thread trimmer and reverse functions.
* 500 watt direct drive servo motor
* DBx1 needle system
* "L" class bobbin
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-W264
Our CEDAR Special CS-W264 is a Direct Drive, Small Cylinder, Cover Stitch Machine
Machine Features:
* Applications: Coverseam, Hemming, etc.
* No. of needles: 2 or 3 needles
* No. of threads: 4 - 5
* Needle Gauges ( 3.2mm, 4.0mm, 5.6mm, 6.4mm)
* Presser Foot Lift: Max, 5.8mm
* Thread Trimming: Top & Bottom available.
* Also available with Top Feed Mechanism.
* Custom Folders are available upon request.
- Different versions of this machine are available. Be sure to check with one of our experienced technicians or sales representatives for specific information.
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-430D-0906
Our CS-430D-0906 industrial, electronic Pattern and Bartack sewing machine. Designed for heavy-duty and high-speed production, it typically sews at up to 3,200 stitches per minute and features a 90 × 60 mm sewing area for bar tacks, box-X patterns, and custom stitching as your choose.
Features:
* Onboard Programming ( Dahao Touch screen )
* PC Programming is also available.
* Electronic Bar Tacking Sewing Machine
* 90mm x 60mm Sewing Field
* 3 pedal system
* Powerful left and right air clamps for maximum holding power!
* Available in other sizes.
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-2640Max
Our CS-2640Max is a heavy-duty compound feed lockstitch sewing machine. It is specifically engineered to handle multi-layered materials and thick fabrics, commonly used in professional manufacturing environments for specialized seaming and heavy textile work. The 2640Max belongs to our premium line of industrial sewing machines.
Key features include:
* Zig Zag, Direct Drive, Industrial Sewing Machine
* Top Feed and Bottom Feed mechanism.
* Compound Feed Mechanism: Features a needle-feed (or unison feed) system, ensuring thick materials are moved evenly without slipping.
* Material Handling: Built to sew heavy-weight textiles, making it ideal for canvas, leather, heavy upholstery, and webbing.
* Specialized Applications: Our 2640 series includes variations tailored for double-needle setups and side-cut lockstitch operations.
Anti Bird nest, Top-down Compound Feed Lockstitch.
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-1968BNF
Our CS-1968BNF Needle Feed machine is one of our newest additions. With the intelligent step motor driven feed mechanisms and operator friendly functions, it is quickly becoming one of our most popular machines.
Key Machine Specifications:
* Single Needle, Needle Feed
* Intelligent Needle feed single needle lockstitch with double step motor driving.
* LED Light
* The machine adopts connecting rod type needle feeding structure, which makes the feeding characteristics more stable, making fabric slips less likely between layers.
* LCD touch screen with simple and clear functions.
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-1291-7D
The CEDAR Special CS-1291-7D is a Needle Feed, Post Bed Machine
Key Features:
* Single Needle
* Direct Drive
* Automatic Foot Lift
* Automatic Thread Trim
* Automatic Back Tack
* Voltage : 220v
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-326G
The CEDAR Special CS-326G is an advanced, direct-drive, programmable electronic pattern sewer with a cylinder bed. It delivers a max sewing speed of 2,700 stitches per minute within a sewing area of 220 mm × 100 mm.
This machine is ideal for heavy-duty stitching on materials like canvas, bags, and mattress handles.
Key Machine Specifications
* Sewing Area: 220 mm × 100 mm (Option for 130 mm × 100 mm).
* Max Sewing Speed: 2,700 stitches per minute.
* Max Stitch Length: 0.05 to 12.7 mm
* Memory Capacity: Up to 512–520 stored programs or patterns.
* Work Clamp Lift: 19.5 mm (presser foot) and 30 mm (clamp foot).
* Onboard or PC Programming.
** Also available with Slide Device for attaching hook, loop, labels, and other hard-to-handle small parts **
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-342G
The CEDAR Special CS-342G is an advanced, direct-drive, programmable electronic pattern sewer with a cylinder bed. It delivers a max sewing speed of 2,300 stitches per minute.
This machine is ideal for heavy-duty stitching on materials like canvas, bags, and mattress handles.
Key Machine Specifications
* Sewing Area: 300 mm × 200 mm (Option for 130 mm × 100 mm).
* Max Sewing Speed: 2,300 stitches per minute.
* Max Stitch Length: 0.05 to 12.7 mm
* Memory Capacity: Up to 512–520 stored programs or patterns.
* Work Clamp Lift: 19.5 mm (presser foot) and 30 mm (clamp foot).
* Onboard or PC Programming.
** Also available with Slide Device for attaching hook, loop, labels, and other hard-to-handle small parts **
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-W664
The CEDAR Special W600 Series is a high-speed, cylinderbed interlock (coverstitch) machine used for plain seaming, hemming, and attaching elastic and can come with different variations such as Left Hand Fabric Trimmer. Depending on the specific version, it has a maximum speed of 6,000 stitches per minute and a stitch length between 0.9 mm and 4.5 mm.
Key specifications for the W600 series include:
* Needle Configurations: 2-needle (3.2, 4.0, 4.8, 5.6, or 6.4mm), 3-needle (5.6 or 6.4mm), and 4-needle (6.0mm) options.
* Presser Foot Lift: Up to 5.9 mm.
* Differential Feed Ratio: Adjustable from 1:0.6 to 1:1.5.
The machine is known for its durability and can be equipped with automated features like underbed thread trimmer, fabric trimmer, top thread trimmer, and direct-drive motor, just to name a few.
** The CS-664-35BB-PUT is available with fabric trim knife **
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-1306
The digital sewing system of the CS-1306HS-22 offers Standard Clamping, Custom Engineered Clamping or Labor Saving Devices that are designed for specific operations.
Key Features and Benefits:
* Sewing Area: 130mm x 60mm.
* Shortened Cycle Time
* Onboard or PC Programmable Patterns.
* Speed: Achieves a maximum sewing speed of 2,500 stitches per minute. The machine reaches this speed by the third stitch and maintains it until the end of sewing, significantly reducing cycle time.
* Thread Trimming: Ensures speedy and consistent thread trimming performance.
* Main-Shaft Direct-Drive System: Enhances machine responsiveness.
* Improved Seam Quality
* Enhanced Feed Accuracy: The encoder-controlled X-Y drive stepping motor improves feed accuracy, reducing pattern deformation when sewing at high speeds or with heavy materials.
* Semi-Dry Head: Utilizes advanced dry technology to prevent oil stains on products.
* Programmable Intermediate Presser
* Adjustable Height: The intermediate presser height can be adjusted steplessly during sewing to accommodate multi-layered materials, preventing stitch skipping and thread breakage.
* Two Types of Feeding Frames
* Monolithic and Separately-Driven: The separately-driven feeding frame allows for easier placement of sewing materials, with adjustable lift and speed for each frame part.
* Double-Stepped Stroke Feeding Frame
* Convenient Positioning: Allows for fine positioning of materials with adjustable stopping height.
* Active Tension
* Precision Control: Enables pinpoint changes in needle thread tension during sewing, adjustable through the operation panel. This reduces setup time for process changes and supports a broader range of sewing conditions.
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-8720D
The CEDAR Special CS-8720D is a Direct Drive, twin-needle, heavy-duty industrial sewing machine. It is designed for making two parallel rows of stitching at the same time. Factories use it for canvas, leather, and heavy fabrics. It can be equipped with a Rear Puller or Side Belt Puller.
The key specifications include:
* Max Speed: Up to 3,000 stitches per minute.
* Stitch Length: Up to 5 mm.
* Needle Feed: Both the needle and the bottom "feed dog" (the metal teeth under the fabric) move to pull thick fabrics evenly.
* Presser Foot Lift: Up to 13 mm with a knee lifter, or 8 mm automatically.
* Needle Type: Uses DP × 5 needles.
* Hook: Uses large vertical rotary hooks for larger bobbins.
External Functions:
* Needle Positioning
* Manual Foot Lift
* Manual Thread Trim
* Manual Back Tack
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
