Machine Brands
Browse our high-performance line of Machine Brands. Built for reliability, durability, and operational efficiency.
Cedar Special
CS-3020H
The CS-3020H is our Heaviest programmable electronic pattern sewing machine for extra heavy duty lifting slings.
The special extra large shuttle hook and bobbin capacity offers high efficiency in sewing products using extra thick thread and has a thread rating up-to Metric size #4, V693, 2000dx3.
Advantages:
* Working Area: 300mm x 200mm
* Maximum Speed: 700 spm
* Trimming Mode: Electrical Heating Cut - Top & Bottom
* Motor: Stepping close-loop motor, synchronous belt, linear guide driven.
* Stitch Length: 0.10 - 12mm
* Presser Foot lifting height: 30mm
* Shuttle: Super Large Shuttle Hook
Can easily sew 6-8 ply synthetic webbing slings (3.5mm of each) or join two ropes and cords together with each of 28mm (independent break testing results show strengths similar to hand splicing, and in some cases exceeding the strength of the rope itself).
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-5114D
The CS-5100D Series is a Direct Drive, Cylinder Bed Overlock Machine with Lower Differential Feed Mechanism. It also comes in a Variable Top Feed Version for heavy fabrics.
* General Specifications:
* Stitch Length Adjustment: Push-Button
* Differential Feed Ratio Adjustment: Lever that can be adjusted intermittently, during sewing.
* Maximum Speed: 7,000 spm (Top Feed 6,00 spm)
* Lubrication: Fully Automatic (internal oil pump)
* Cylinder Circumference: 148mm
* Top Feed version feeds the fabric accurately without ply shift or twist.
* Top Feed version can be utilized with light to heavy fabrics.
* Flat Bed style plate available for multi-use setup.
* Alternate Devices & Attachments:
* Roller guide assembly (tensioner style or basic)
* Upper Metering Device for attaching elastic.
* Round Collar
* Tape Cutter
* Chain Cutter
* Automatic Foot Lift
* Hemming Guide
* Pneumatic trimming & lint collector
* Available Stitch Formations:
* 503, 1 needle thread + 1 looper thread
* 504, 1 needle thread + 2 looper threads
* 505, 1 needle thread + 2 looper threads
* 512, 2 needle threads + 2 looper threads
* 514, 2 needle threads + 2 looper threads
* Custom Folders, Guides and Accessories are available.
- Special Automated Machines are Available. Check with one of our experienced sales representatives -
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-8720B
The CEDAR Special CS-8720B is a Direct Drive, twin-needle, heavy-duty industrial sewing machine. It is designed for making two parallel rows of stitching at the same time and is equipped with an Operator Friendly Touch Button Panel for Programming.
Uses:
* Factories use it for canvas, leather, and heavy fabrics. It can be equipped with a Rear Puller or Side Belt Puller.
The key specifications include:
* Max Speed: Up to 3,000 stitches per minute.
* Stitch Length: Up to 5 mm.
* Needle Feed: Both the needle and the bottom "feed dog" (the metal teeth under the fabric) move to pull thick fabrics evenly.
* Presser Foot Lift: Up to 13 mm with a knee lifter, or 8 mm automatically.
* Needle Type: Uses DP × 5 needles.
* Hook: Uses large vertical rotary hooks for larger bobbins.
* Needle Gauges: Available gauge set sizes: 1/8" (3.2 mm), 3/16" (4.8 mm), 1/4" (6.4 mm), 3/8" (9.5 mm), up to 1/2" (12.7 mm) and higher depending on the specific application block installed.
* Custom Folders, Binders and Guides for the Sewn Products Industry
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-8720A
The CEDAR Special CS-8720A is a Direct Drive, twin-needle, heavy-duty industrial sewing machine. It is designed for making two parallel rows of stitching at the same time and is equipped with an Operator Friendly LCD Panel for Programming.
Uses:
* Factories use it for canvas, leather, and heavy fabrics. It can be equipped with a Rear Puller or Side Belt Puller.
The key specifications include:
* Max Speed: Up to 3,000 stitches per minute.
* Stitch Length: Up to 5 mm.
* Needle Feed: Both the needle and the bottom "feed dog" (the metal teeth under the fabric) move to pull thick fabrics evenly.
* Presser Foot Lift: Up to 13 mm with a knee lifter, or 8 mm automatically.
* Needle Type: Uses DP × 5 needles.
* Hook: Uses large vertical rotary hooks for larger bobbins.
* Needle Gauges: Available gauge set sizes: 1/8" (3.2 mm), 3/16" (4.8 mm), 1/4" (6.4 mm), 3/8" (9.5 mm), up to 1/2" (12.7 mm) and higher depending on the specific application block installed.
* Custom Folders, Binders and Guides for the Sewn Products Industry
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-872D
The CEDAR Special CS-872D is a Belt Driven, twin-needle, heavy-duty industrial sewing machine. It is designed for making two parallel rows of stitching at the same time and is equipped with an Operator Friendly LCD Panel for Speed and Positioning controls.
Uses:
* Factories use it for canvas, leather, and heavy fabrics. It is ideal to be equipped with a Rear Puller or Side Belt Puller for long runs.
The key specifications include:
* Max Speed: Up to 3,000 stitches per minute.
* Stitch Length: Up to 5 mm.
* Needle Feed: Both the needle and the bottom "feed dog" (the metal teeth under the fabric) move to pull thick fabrics evenly.
* Presser Foot Lift: Up to 13 mm with a knee lifter.
* Needle Type: Uses DP × 5 needles.
* Hook: Uses large vertical rotary hooks for larger bobbins.
* Needle Gauges: Available gauge set sizes: 1/8" (3.2 mm), 3/16" (4.8 mm), 1/4" (6.4 mm), 3/8" (9.5 mm), up to 1/2" (12.7 mm) and higher depending on the specific application block installed.
* Custom Folders, Binders and Guides for the Sewn Products Industry
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-8722DP
The CS-8722DP is an Automated Sewing Station, designed specifically for Top Stitching Waist Bands.
The machine head is a Twin Needle, Needle Feed accompanied by a Rear Puller mechanism.
Machine Features:
* User Friendly, Ergonomic Work Station
* Automatic Back Tack
* Automatic Presser Foot Lift
* Automatic Thread Trim
* Easy Adjustable, Pneumatically Engaged - Roller Guiding System
* State of the art, Electronic Control System
* Premium Micro-Adjustable Edge Guide
* Custom Folders, Binders and Guides for the Sewn Products Industry.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-12080
Our CS-12080 is one of our larger Programmable Pattern machine. Used in operations like Home Décor, Large Interior Patterns to be seamless and much more.
* Some features of the machine include:
* Sewing Speed: 2,500 spm, (XY Axis moving speed maximum 10meters/minute.
* Hook: 2X Japan Hirose Hook / Koban Hook (3X Size Hook is Optional).
* Uses latest A8 CPU, Disk/USB Date Memory, XYZ Servo Motor, Highly Accurate (to 0.001mm).
* All templates work with Intelligent Judgement.
* Thread - Break Detector. (Bottom thread stitch quantity is optional).
*Sewing Area: X = 1,200mm, Y = 800mm. Larger sizes are available.
* Needle Type: DPx5 / DPx17
* Sewing Thickness: 0.1mm - 10mm.
* Presser Foot: Electropneumatic.
* Applications: Tents, Sleeping Mats, Drapes, Banners, etc...
In this video, we are sewing more than 200 MOLLE Style Bar Tacks per pallet. The right and left sides of the webbing is hot cut and turned under.
The 2nd pallet in this video has longer left and right tabs to be able to reach over the extended panel to hold the folded webbing.
This machine is equipped with a bar code reader that switches the program automatically between pallets.
Thanks for watching and sharing our videos. I hope you enjoy the video as much as we enjoy building Automated Machines for the Industrial Sewing Industry.
* Custom Designed Pallet Systems are available.
* Custom Folders, Binders and Guides for the Sewn Products Industry.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Lexington, Alabama 35648
• CEDAR Systems Automated Sewing Machines & Devices
• VMW Automated Sewing Equipment
• Tice Engineering
Cedar Special
CS-E380ND
The CS-E380ND is an industrial multi-needle chain stitch sewing machine. High-speed, flat-bed, parallel 2-Needle or 3-Needle chainstitch, built for heavy-duty garment manufacturing like jeans and workwear.
- It features Servo motor control for thread cutting and an automatic foot lifter -
* Machine Highlights
* Heavy-Duty Power: Built to handle extremely thick materials, such as 16 layers of heavy denim fabric.
* Smart Controls: Uses a step motor to manage automatic presser foot lifting.
* Multi-Needle Setup: Designed with optimized needle positions for specialized chain stitching tasks.
* Key Performance Specs
* Max Needle Distance: 5mm overall
* Max Speed: 4,000 stitches per minute
* Stitch Length: Up to 4 mm (adjusted via a stitch dial)
* Presser Foot Lift: 5 mm by hand, 13 mm by knee
* Needle Type: TVx7 (sizes #14 to #18)
* Lubrication: Automatic
* Core Features
* 2-Needle or 3-Needle Setup: Sews multiple rows of chain stitch at the same time to boost output.
* Condense Stitching: Uses an easy-to-reach lever to lock/reinforce end stitches to help prevent raveling.
* Durable Looper: Features an inclined crank rocking-type looper designed for long-term stability with minimal wear.
* Custom Folders, Binders and Guides for the Sewn Products Industry.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Lexington, Alabama 35648
• CEDAR Systems Automated Sewing Machines & Devices
• VMW Automated Sewing Equipment
• Tice Engineering
Cedar Special
CXT2241
Our CEDAR Special CXT2241-52P2 has a Top Feed to assist the bottom feed for Binding Heavy Fabrics with a Single Needle 401 Stitch Type. At 7,000 spm, it does a wonderful job.
Our premium line of Overlock and Safety Stitch Machines have become one of the best lines on the market. Paired with our technical staff, virtually unmatched in the industry.
Key Features
* Tape Cutter: Programmable, Pneumatic
* Foot Lift: Automatic - Pneumatic
* Stitch Length Adjustment: Push Button
* Dust & Waste Collector: Pneumatic
* Differential Feed Ratio Adjustment: Lever with Mirco-Adjuster
* Lubrication: Automatic
* Fabric Weight: Light - Medium
* Maximum Speed: 7,000 spm
* No. of Needles: 1
* No. of Threads: 2
* Maximum Tape Width: 24mm (wider may be achieved with custom modifications)
* Stitch Type: 401
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-6040+
Our CS-6040+ ( 600mm x 400mm ) is also available as a CS-10040 ( 1000mm x 400mm ) and represent some of our larger Programmable Pattern machines. Used in operations like Home Décor, Large Interior Patterns to be seamless and much more.
Some features of the machine include:
* Sewing Speed: 2,500 spm, (XY Axis moving speed maximum 10meters/minute.
* Hook: 2X Japan Hirose Hook / Koban Hook (3X Size Hook is Optional).
* Uses latest A8 CPU, Disk/USB Date Memory, XYZ Servo Motor, Highly Accurate (to 0.001mm).
* All templates work with Intelligent Judgement.
* Thread - Break Detector. (Bottom thread stitch quantity is optional).
* Needle Type: DPx5 / DPx17
* Sewing Thickness: 0.1mm - 10mm.
* Presser Foot: Electropneumatic.
* Applications: Tents, Sleeping Mats, Drapes, Banners, etc...
Thanks for watching and sharing our videos. I hope you enjoy the video as much as we enjoy building Automated Machines for the Industrial Sewing Industry.
* Custom Designed Pallet Systems are available.
* Custom Folders, Binder and Guides for the Sewn Products Industry.
For more information, please call or email.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Cedar Special
CS-2533-7C
The CS-2533-7C is a Direct Drive, Top & Bottom Feed, Single-Step Zigzag.
Primary Features:
* 2-Step x 3-Point
* Full function machine utilizes a synchronized top-and-bottom feed mechanism to prevent slippage when sewing thick, heavy layers. Designed for materials like leather, canvas, neoprene, and upholstery.
* Complimented with Automatic Thread Trim, Automatic Back Tack and Automatic Foot Lift.
* Custom Folders, Guides, Clamps and Pallets are available.
• Phone: (256) 229-6595
• Email: Sales@CollierEquipment.com
Mauser Spezial
Mauser-Spezial Press
This page has pictures and other information from past exhibitions featuring Mauser Spezial machinery that includes the following:
* Mauser Spezial Model #: MA-269
Single Needle, Cylinder Bed Walking Foot
* Mauser Spezial Model #: MB1900
Electronic - Programmable Tacker 40mm x 30mm
* Mauser Spezial Model #: MH-1296
Double Needle, Post Bed, Walking Foot
* Mauser Spezial Model #: MH-1341
Single Needle, Top & Bottom Feed, Direct Drive (Air is not required)
* Mauser Spezial Model #: MH-1641
Single Needle, Top & Bottom Feed, Direct Drive (Air is required)
* Mauser Spezial Model #: MH-2642
Single Needle or Double Needle, Needle Feed
* Mauser Spezial Model #: MH-2645
Single Needle or Double Needle, Waking Foot
* Mauser Spezial Model #: MH-2645-750
Single Needle or Double Needle, Walking Foot with 750mm Working Area
* Mauser Spezial Model #: MM1020-C
Double Needle Cover Stitch for making Belt Loops
* Mauser Spezial Model #: MP-2210
Programmable Pattern Tacking Machine 220mm x 100mm
* Mauser Spezial Model #: MS-0591
Post Bed, Wheel Feed Machine for sewing 3D Products and Patches
* Custom Folders, Binders, Guides and Clamps Sets for the Sewn Products Industry.
For more information, call or email.
Phone: (256) 229-6595
Email: Sales@CollierEquipment.com
